Colliders

A collider gives a body its shape for the physics solver. Colliders are declared by the collider schema (packages/engine/src/scene/schema/collider.ts).

Shapes

The four collider shapes.

type	Sizing fields
cuboid	halfExtents ([x, y, z] half-size)
ball	radius
capsule	radius + halfHeight
trimesh	built from the entity’s mesh geometry

All sizing fields are authored in the entity’s own local units. The loader bakes in the entity’s composed world scale (self × every transformed ancestor) once at load time — Rapier has no live notion of an Object3D’s scale — so a collider’s world-space size always matches whatever ends up on screen. Round colliders (ball, capsule) can only represent a uniform radius: a non-uniform world scale on their round axes throws a loud load error naming the entity.

Material properties

• friction — surface friction coefficient.
• restitution — bounciness (0 = no bounce, 1 = perfect bounce).
• density — mass density; the body’s mass is computed from density × collider volume (unless mass is set on the body).
• offset — translation of the collider relative to the body origin, in the entity’s own local units; scales with the entity’s composed world scale the same way the sizing fields above do.

Sensors (trigger volumes)

Set isSensor: true to make a collider detect overlaps without physically blocking. Sensors are how you build trigger zones (checkpoints, pickups, damage volumes) — they fire onTriggerEnter / onTriggerExit instead of resolving contacts. See Collisions & triggers.

Collision layers

Two bitmasks (each up to 16 bits) control what interacts with what:

• collisionGroups — the layers this collider belongs to.
• collisionFilter — the layers this collider interacts with.

Two colliders interact only when each one’s group is in the other’s filter. Name your 16 layers in the scene environment so the masks read meaningfully.

The physics debug view

Press P at runtime to toggle a wireframe overlay of every collider, drawn from rapierWorld.debugRender() into a Three.js LineSegments (packages/engine/src/setup/setup-physics.ts). It’s the fastest way to confirm a collider’s shape and placement match the visual mesh.

The running scene with the physics debug overlay (toggled with P).

Trimesh colliders are static

trimesh colliders are for static geometry (terrain, level meshes). For moving bodies use a primitive (cuboid/ball/capsule) — it’s faster and more robust.

See also

• Rigid bodies — what a collider attaches to.
• Collisions & triggers — reacting to overlaps.
• Scene Schema reference — every collider field.
